Ref: CT-540X10
Longer life
- Cells embedded in EVA (Ethylene Vinyl Acetate)
- Protective glass on the front side
- Water and weather resistant rear side
- Modules equipped with By-Pass diodes - 3 diodes
Durable frame
- All-aluminium frame
- Screwed frame on both sides
- Simple installation
- Easy to connect socket
Quality finish
- Optics, mechanics and electrical module tested during and after production
- Automated production ensuring high quality of production
Guarantees & Certificates
- 12 year warranty for 90% efficiency
- 25 years warranty for 80% efficiency
- 10 years hardware warranty
- IEC 61215, IEC 61730, TÜV Safety Class II, CE, ISO, RoHS, MCS, BRE Global Listed, PV Cycle, ISO, UL, Clean Energy Council Member, Bankable
1 Photovoltaic panel 540 Wp.
30 days to retract
Free delivery in Europe 3 - 5 working days
540 Wp Solar Panel Monocrystalline CT-540X10
Rating is 0.0 out of five stars based on reviews
SKU: CT-540X10
€124.20Price
Technical features
Number of Cells 144 (6 × 24) Cell size: 182mm x 182mm Panel Dimensions: 2279 x 1134 x 32mm Certificate: IEC 61215/IEC 61730/CE/FIDE/INMETRO Connector: MC4 Compatible Glass: 3.2mm High Transmission, Antireflection Coating Maximum system voltage:
1500V DC Maximum series
fuse rating:
25A Type: All Black, Half Cell, PERC Panel Efficiency 21.67% Junction box: IP68, 3 Bypass Diodes Cable: 4.0mm2, 300/400mm in length Operating Temperature: -40 ~ +85°C Application level:
Class A Nominal operating cell
temperature:
45°C±2°C Open-circuit Voltage
(Voc)
49.8V Maximum Power Voltage (Vmp) 42V Short-circuit Current (Isc) 13.66A Maximum Power Current (Imp) 12.86A Module Efficiency 20.89%
